Distance between centers: 350mm

Max. Swing Dia. Over Bed: 180mm

Max. Swing Dia. Over Cross Slide: 110mm

Chuck diameter: 100mm

Taper Of Spingdle Bore: MT3

Hole Through Spindle: 33mm



Range of spindle speeds: 50 ~2500rpm

Metric threads: 0.1-0.2mm

Top side travel: 35mm

Cross side travel: 65mm

Bottom side travel: 195mm

Tailstock sleeve travel: 40mm

Taper of tailstock sleeve: MT2

Size: 750mm*215mm*305mm



Power: 600W 220V 50HZ

N.W.: 45 KG
